Impact: Gradual erosion of insulation, eventually causing catastrophic failure. Busbars in power systems are the location where transmission lines, generation sources, and distribution loads converge. Because of this convergence, short circuits located on or near the busbar tend to have very high magnitude currents. Busbars are key elements in many electrical distribution network systems, such as switchgear assemblies, electric vehicle charging infrastructure, renewable energy systems (solar/PV wind), data centers, industrial electrical panels, substations, and manufacturing sites. To protect these vital nodes, engineers must first understand the specific types of electrical faults that can threaten them.
