①Multimode fiber optic module: The pull tap is black, corresponding to a wavelength of 850nm, suitable for short-distance transmission (such as less than 2km). This article provides a professional guide on transceiver pull tab color codes by wavelength—spanning SFP, SFP+, CWDM, and BiDi modules—and introduces how LINK-PP standardizes. One of the most effective and widely used methods is through the pull-tab color on transceiver modules. In the complex infrastructure of data centers, optical modules are critical components that. Each SFP module operates at a specific wavelength, and to avoid confusion, manufacturers use color-coded pull rings for easy identification. Here's a quick guide: 🔹 850nm (Black) – Short-distance multimode fiber (up to 550m) 🔹 1310nm (Blue) – Longer reach, typically used for single-mode fiber (up. These modules convert electrical signals into optical signals, which transmit data over distances of fiber optic cables with minimal power loss.
