Switchgear busbar color standard
Home / Switchgear busbar color standard
The color regulations of switchgear mainly concern electrical safety and identification. Busbar color scale Three-phase AC busbar: Phase A is yellow, Phase B is green, and Phase C is red DC Bus: positive red, negative blue Simulates the logo color of the busbar . This standard defines the design verification, test requirements, and thermal performance of the assemblies. The test shall be carried out according to IEC 60068-2-2 Test Bb, at a temperature of 70 °C, with natural air circulation, for a duration of 168 h (7 days) and with a recovery of 96 h (4 days). They represent indispensable principles that modern power system engineers must thoroughly. A busbar is a metallic bar or strip—typically copper or aluminum—mounted inside switchgear/switchboards to distribute high currents.
